AltiCam Vision Product Summary Table

  09 MWIR1 09 MWIR2 09 EOIR1-P 09 EO1 11 EOIR1 11 EOIR2 07 EO1
Field of View 2.5°, 10° 2°-25° MWIR: 2°-25°
EO: 1.1°-25°		 0.29°-58° MWIR: 2.5° and 10°
LWIR: 18°
EO: 1.7°-57°		 MWIR: 2°-25°
EO: 1.7°-57°		 1.7°-56°
Pixels 640X480 640X480 MWIR: 640 x 480
EO: 720 x 480		 640 x 480
 MWIR: 640 x 480
LWIR: 320 x 240
EO: 720 x 480		 MWIR: 640 x 480
EO: 720 x 480		 720 x 480
Wavelength 3 - 5 µm 3 - 5 µm MWIR: 3-5 nm
EO: 400-900 nm		 400-900 nm MWIR: 3-5nm
LWIR: 8-12 nm
EO: 400-900 nm		 MWIR: 3-5 nm
EO: 400-900 nm		 400-900 nm
Zoom (optical) Two positions; 2.5° and 10° 12.5X MWIR: 12.5X
EO: 36X		 200X Continuous MWIR: 2.5° and 10°
LWIR: 1X
EO: 36X		 MWIR: 12.5X
EO: 36X 		36X
Gimbal Sequence Roll-over-Tilt Roll-over-Tilt Roll-over-Tilt Roll-over-Tilt Pan-over-Tilt Pan-over-Tilt Pan-over-Tilt
Tilt -25° forward to +35° back 80° forward to 45° back 80° forward to 45° back 80° forward; 45° back 30° up; 90° down 30° up; 90° down 30° up; 110° down
Pan/Roll 360° (endless roll) 360° (endless roll) 360° (endless roll) 360° (endless roll) 360° (endless roll) 360° (endless roll) 360° (endless roll)
Slew Rate 45°/sec 45°/sec 45°/sec 45°/sec 45°/sec 45°/sec 50°/sec
Performance @ 1Hz TBD TBD TBD 39 dB and 38 dB attenuation TBD TBD 30 dB attenuation
Communications Nominal: Serial communication, 57,600 bps Nominal: Serial communication, 57,600 bps Nominal: Serial communication, 57,600 bps Serial communication, 57,000 bps, AltiCam command set Nominal: Serial communication, 57,600 bps Nominal: Serial communication, 57,600 bps Nominal: Serial communication, 57,600 bps
Video Composite NTSC Composite NTSC Composite NTSC Composite NTSC Composite NTSC Composite NTSC Composite NTSC
Power 12 VDC-14 VDC 13.2 VDC, 18 W, 22 W peak 13.2 VDC, 17 W, 26 W peak 13.2 VDC, 12 W Continuous, 20 W Peak 28 VDC, 31 W, 55 W Peak 28 VDC, 31 W, 55 W Peak 11-24 VDC, 7 W
Weight 2900 g (3400 g with enclosure) 2900 g (3500 g with enclosure) 2660 g (3370 g with enclosure) 2775g (3470 g with enclosure) 5550 g with enclosure 5700 g with enclosure 1020 g
Mounting ScanEagle Standard Fuselage Clip Pattern ScanEagle Standard Fuselage Clip Pattern ScanEagle Standard Fuselage Clip Pattern ScanEagle standard fuselage clip pattern Integrator Standard Payload Pattern Integrator Standard Payload Pattern ScanEagle Standard Nose Pattern
Dimensions 30 cm length X 22 cm Ø cylinder 30 cm length X 20 cm Ø cylinder 30 cm length X 20 cm Ø cylinder 30 cm length X 20 cm Ø cylinder 25.4 cm Ø Sphere 25.4 cm Ø Sphere 18 cm Ø Sphere
Laser Pointer N/A 830 nm, 150 mW, 0.5 mrad 830 nm, 150 mW, 0.5 mrad N/A 830nm, 50 mW, 0.5 mrad 830nm, 50 mW, 0.5 mrad N/A
Laser Range Finder N/A N/A N/A N/A 3000 m 3000 m N/A

AltiCam Vision Turret Models

AVS 1000 Video Processing Image stabilizing, tracking, and enhancement compatible with all ALTICAM products
ALTICAM SNAKE EYES Rugged hand-held UAV video monitoring unit
ALTICAM 07 EO1 Light-weight EO imager in a stabilized turret
ALTICAM 09EO1 200X zoom EO imager in a stabilized turret
ALTICAM 09 MWIR1 Medium-wavelength IR imager in a stabilized turret
ALTICAM 09 MWIR2 Continuous focus medium-wavelength IR imager in a stabilized turret
ALTICAM 09 EOIR1-P Continuous focus medium-wavelength IR and EO imagers and laser marker in a stabilized turret
ALTICAM 11 EOIR 1 EO, medium-wave IR, and long-wave IR imagers along with a laser range finder and laser marker in a stabilized turret
ALTICAM 11 EOIR 2 EO and medium-wave IR imagers along with a laser range finder and laser marker in a stabilized turret
